2 in 1 detergent pods packing machine laundry capsules filling machine

2 in 1 detergent pods packing machine laundry capsules filling machine

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Unit-dose pva water soluble pouches laundry detergent pods filling packing machine



Product Description

 Introduction

NZB-10 series automatic laundry pods packing machine is a rotary drum-type unit dose non aqueous liquid pods forming, filling, sealing and cutting equipment. It is an automatic high capacity water-sealing packing machine specially designed for high concentrated laundry detergent pods. It has good adaptability of water soluble PVA film and detergent liquid.



 1.      Rotary drum-type liquid filling, servo motor driving, which ensure precise control of production consistency, production pace flexibility.

2.      Plunger pump filling system, accurate dosing. Well corrosion resistance and high reliability filling system.

3.      CNC machining mould cavity, which guarantee the uniformity, consistency of the detergent pods shape.

4.      Self-designed water cool sealing structure reduces sealing temperature, greatly protect the water solubility of PVA film.

5.      Integrated cutting system for finished product, horizontal and vertical cuts along with the roller moving. It keep consistent rate of the drum which provides good production consistency.

6.      Adopts PLC control. temperature, pressure, speed and other parameters can be set via the human-computer interface touch screen.

7.      Adopts famous brands (Schneider, Mitsubishi) main electronic components. Long service life.









Parameter Sheet



Min Capacity

300pcs/min

Max Capacity

600pcs/min

Forming drum

10 lanes * 48 row

Packing volume

10-30g(customized)

Weight tolerance

±0.05g

Dimension

L3500×W1150×H2350mm



Machine trail and customer training



Certifications

 Patents for film transfer unit, rotary drum forming unit, film clamping, sealing and the whole machine design



We are the only one supplier in China who are capable of manufacturing PVA film exactly for laundry detergents capsules















FAQ



Q. What are the main application of PVA film ?

A.:The main application of PVA water soluble film includes liquid or powder laundry detergent pods packing, pesticide packing , water transfer printing ,medical laundry bags and so on.



Q. What is the advantage of PVA water soluble detergent packets over the regular detergent packaging ?

A.:Using the single dose detergent packet is more convenient, more rational, more scientific and greener



Q. What machinery can run water-soluble films?

A. Horizontal flow wrapping machines, thermoforming machines and vacuum forming machines (horizontal and rotary) may run this film. Vertical Form Fill, Seal machines (trans wrap type), some types of stick pack machines, some types of 3 side and 4 side seal Vertical Form Fill and Seal machines, pleat wrapping and cut and wrap block wrapping machines are all able to run water-soluble films.



Q. How much weight can a water-soluble bag hold?

A. Laundry bags are expected to contain a maximum of 12kg (26 lbs) of linen when loaded into a supporting outer transport bag.  Chemical packages are typically up to 10kg, though there is not theoretical reason for higher loadings given correct filling and handling.



Q: what are the special advantages of your products?

A: our company's product raw material USES all is harmless material, assure user's safety.

Our products are more suitable for packaging machine and improve packaging efficiency.

Our company's product weatherability reaches the same level of foreign products, as far as possible to reduce the customer's use of environment and storage environment requirements.





Since its establishment, POLYVA has won the recognition of water soluble plastic bags. Located in Nanhai High-tech Zone, our factory covers 3300 square meters with over 60 employees. Professional team are equipped with to accelerate POLYVA to be the leading water soluble plastic bags manufacturer. Located in Nanhai High-tech Zone, our factory covers 3300 square meters with over 60 employees.
