PVA plastic film roll for agrochemicals water soluble sachet
Water soluble PVA film for agrochemicals packaging
(fertilizer, pesticide, herbicide)
Product Features
1. Completely dissolve, no residue left.
2. Good weather resistance,
3. Green environment-friendly material, no toxic substance contain.
4. Good mechanical property and heat sealing ability.
5. Able to be printed with good quality, ink will dissolve with the bag.
|
Thickness(um) |
20,25,30,35,40,45,50 |
|
Width (mm) |
1000 |
|
Length (m) |
100~1000 |
Technical data
Test Sample: 35 micron, test condition:23℃,50%RH
|
Test condition |
Disintegration time (Begin) |
Solution time (complete) |
|
Water temperature 23℃ |
<10 sec |
<40 sec |
Test Sample: 35 micron, test condition:23℃,50%RH
|
Item |
Test standard |
NY300 series |
NY700 series |
|
Tensile strength MPa |
GB/T 1040-2006 |
≥30 |
≥20 |
|
Elongation at break % |
GB/T 1040-2006 |
≤300 |
≥300 |
|
100% stretching strength % |
GB/T 1040-2006 |
≥10 |
≥5 |
|
Elastic modulus MPa |
GB/T 1040-2006 |
≥50 |
≥25 |
|
Heat sealing strength 0.035mm, N/15mm |
GB/T 1040-2006 |
≥5 |
≥5 |
PVA film for laundry capsules
NZB-10 series automatic laundry pods packaging machine
Machine trail and customer training
Patents for film transfer unit, rotary drum forming unit, film clamping, sealing and the whole machine design
Film & pods testing
